Package jmri.jmrit.display

Class DisplayFrame

java.lang.Object

java.awt.Component

java.awt.Container

java.awt.Window

java.awt.Frame

javax.swing.JFrame

jmri.util.JmriJFrame

jmri.jmrit.display.DisplayFrame

All Implemented Interfaces:

ComponentListener, WindowListener, ImageObserver, MenuContainer, Serializable, EventListener, Accessible, RootPaneContainer, WindowConstants, BeanInterface, ModifiedFlag, WindowInterface

Direct Known Subclasses:

ItemPalette

public class DisplayFrame
extends JmriJFrame

Extended JmriJFrame that allows to add an InitEventListener for display of a tabbed frame in the CPE Add Item ItemPalette pane.

See Also:

• Serialized Form

Nested Class Summary

Nested classes/interfaces inherited from class jmri.util.JmriJFrame

JmriJFrame.ScreenDimensions

Nested classes/interfaces inherited from class javax.swing.JFrame

JFrame.AccessibleJFrame

Nested classes/interfaces inherited from class java.awt.Frame

Frame.AccessibleAWTFrame

Nested classes/interfaces inherited from class java.awt.Window

Window.AccessibleAWTWindow, Window.Type

Nested classes/interfaces inherited from class java.awt.Container

Container.AccessibleAWTContainer

Nested classes/interfaces inherited from class java.awt.Component

Component.AccessibleAWTComponent, Component.BaselineResizeBehavior, Component.BltBufferStrategy, Component.FlipBufferStrategy

Nested classes/interfaces inherited from interface jmri.util.swing.WindowInterface

WindowInterface.Hint

Field Summary

Fields

Modifier and Type	Field	Description
(package private) static Color	_darkGrayColor
(package private) static Color	_grayColor
(package private) static final Color[]	colorChoice

Fields inherited from class jmri.util.JmriJFrame

allowInFrameServlet, properties, reuseFrameSavedPosition, reuseFrameSavedSized, windowInterface

Fields inherited from class javax.swing.JFrame

accessibleContext, rootPane, rootPaneCheckingEnabled

Fields inherited from class java.awt.Frame

CROSSHAIR_CURSOR, DEFAULT_CURSOR, E_RESIZE_CURSOR, HAND_CURSOR, ICONIFIED, MAXIMIZED_BOTH, MAXIMIZED_HORIZ, MAXIMIZED_VERT, MOVE_CURSOR, N_RESIZE_CURSOR, NE_RESIZE_CURSOR, NORMAL, NW_RESIZE_CURSOR, S_RESIZE_CURSOR, SE_RESIZE_CURSOR, SW_RESIZE_CURSOR, TEXT_CURSOR, W_RESIZE_CURSOR, WAIT_CURSOR

Fields inherited from class java.awt.Component

BOTTOM_ALIGNMENT, CENTER_ALIGNMENT, LEFT_ALIGNMENT, RIGHT_ALIGNMENT, TOP_ALIGNMENT

Fields inherited from interface java.awt.image.ImageObserver

ABORT, ALLBITS, ERROR, FRAMEBITS, HEIGHT, PROPERTIES, SOMEBITS, WIDTH

Fields inherited from interface javax.swing.WindowConstants

DISPOSE_ON_CLOSE, DO_NOTHING_ON_CLOSE, EXIT_ON_CLOSE, HIDE_ON_CLOSE

Constructor Summary

Constructors

Constructor	Description
DisplayFrame()	Create a JmriJFrame with standard settings, including saving/restoring of size and position.
DisplayFrame(boolean saveSize, boolean savePosition)	Create a JmriJFrame with standard settings, optional save/restore of size and position.
DisplayFrame(String name)	Create a JmriJFrame with with given name plus standard settings, including saving/restoring of size and position.
DisplayFrame(String name, boolean saveSize, boolean savePosition)	Create a JmriJFrame with with given name plus standard settings, including optional save/restore of size and position.
DisplayFrame(String name, Editor editor)	Create a JmriJFrame for ItemPalette or for edit popups of a given editor panel.

Method Summary

Modifier and Type	Method	Description
BufferedImage	getBackground(int index)
Color	getCurrentColor()
Editor	getEditor()
BufferedImage	getPreviewBackground()
int	getPreviewBg()
void	reSize(Container container, Dimension deltaDim, Dimension newDim)	Resizes this frame to accommodate the size of the tab panel when tab is changed.
void	setPreviewBg(int index)	This may be used as a callback to notify children of this class when the preview color has changed.
void	updateBackground(Editor ed)	Called when the background of the display panel is changed.

Methods inherited from class jmri.util.JmriJFrame

addHelpMenu, componentHidden, componentMoved, componentResized, componentShown, dispose, generateWindowRef, getAllowInFrameServlet, getEscapeKeyAction, getEscapeKeyClosesWindow, getFrame, getFrame, getFrameList, getFrameList, getIndexedProperty, getMaximumSize, getModifiedFlag, getPreferredSize, getProperty, getPropertyNames, getSavePosition, getSaveSize, getScreenDimensions, getWindowFrameRef, getWindowInterface, handleModified, hasIndexedProperty, hasProperty, initComponents, makePrivateWindow, makePublicWindow, markWindowModified, multipleInstances, pack, setAllowInFrameServlet, setEscapeKeyAction, setEscapeKeyClosesWindow, setFrameLocation, setIndexedProperty, setModifiedFlag, setProperty, setSavePosition, setSaveSize, setShutDownTask, setWindowInterface, show, show, storeValues, undecorate, windowActivated, windowClosed, windowClosing, windowDeactivated, windowDeiconified, windowIconified, windowOpened

Methods inherited from class javax.swing.JFrame

addImpl, createRootPane, frameInit, getAccessibleContext, getContentPane, getDefaultCloseOperation, getGlassPane, getGraphics, getJMenuBar, getLayeredPane, getRootPane, getTransferHandler, isDefaultLookAndFeelDecorated, isRootPaneCheckingEnabled, paramString, processWindowEvent, remove, repaint, setContentPane, setDefaultCloseOperation, setDefaultLookAndFeelDecorated, setGlassPane, setIconImage, setJMenuBar, setLayeredPane, setLayout, setRootPane, setRootPaneCheckingEnabled, setTransferHandler, update

Methods inherited from class java.awt.Frame

addNotify, getCursorType, getExtendedState, getFrames, getIconImage, getMaximizedBounds, getMenuBar, getState, getTitle, isResizable, isUndecorated, remove, removeNotify, setBackground, setCursor, setExtendedState, setMaximizedBounds, setMenuBar, setOpacity, setResizable, setShape, setState, setTitle, setUndecorated

Methods inherited from class java.awt.Window

addPropertyChangeListener, addPropertyChangeListener, addWindowFocusListener, addWindowListener, addWindowStateListener, applyResourceBundle, applyResourceBundle, createBufferStrategy, createBufferStrategy, getBackground, getBufferStrategy, getFocusableWindowState, getFocusCycleRootAncestor, getFocusOwner, getFocusTraversalKeys, getIconImages, getInputContext, getListeners, getLocale, getModalExclusionType, getMostRecentFocusOwner, getOpacity, getOwnedWindows, getOwner, getOwnerlessWindows, getShape, getToolkit, getType, getWarningString, getWindowFocusListeners, getWindowListeners, getWindows, getWindowStateListeners, hide, isActive, isAlwaysOnTop, isAlwaysOnTopSupported, isAutoRequestFocus, isFocusableWindow, isFocusCycleRoot, isFocused, isLocationByPlatform, isOpaque, isShowing, isValidateRoot, paint, postEvent, processEvent, processWindowFocusEvent, processWindowStateEvent, removeWindowFocusListener, removeWindowListener, removeWindowStateListener, reshape, setAlwaysOnTop, setAutoRequestFocus, setBounds, setBounds, setCursor, setFocusableWindowState, setFocusCycleRoot, setIconImages, setLocation, setLocation, setLocationByPlatform, setLocationRelativeTo, setMinimumSize, setModalExclusionType, setSize, setSize, setType, setVisible, show, toBack, toFront

Methods inherited from class java.awt.Container

add, add, add, add, add, addContainerListener, applyComponentOrientation, areFocusTraversalKeysSet, countComponents, deliverEvent, doLayout, findComponentAt, findComponentAt, getAlignmentX, getAlignmentY, getComponent, getComponentAt, getComponentAt, getComponentCount, getComponents, getComponentZOrder, getContainerListeners, getFocusTraversalPolicy, getInsets, getLayout, getMinimumSize, getMousePosition, insets, invalidate, isAncestorOf, isFocusCycleRoot, isFocusTraversalPolicyProvider, isFocusTraversalPolicySet, layout, list, list, locate, minimumSize, paintComponents, preferredSize, print, printComponents, processContainerEvent, remove, removeAll, removeContainerListener, setComponentZOrder, setFocusTraversalKeys, setFocusTraversalPolicy, setFocusTraversalPolicyProvider, setFont, transferFocusDownCycle, validate, validateTree

Methods inherited from class java.awt.Component

action, add, addComponentListener, addFocusListener, addHierarchyBoundsListener, addHierarchyListener, addInputMethodListener, addKeyListener, addMouseListener, addMouseMotionListener, addMouseWheelListener, bounds, checkImage, checkImage, coalesceEvents, contains, contains, createImage, createImage, createVolatileImage, createVolatileImage, disable, disableEvents, dispatchEvent, enable, enable, enableEvents, enableInputMethods, firePropertyChange, firePropertyChange, firePropertyChange, firePropertyChange, firePropertyChange, firePropertyChange, firePropertyChange, firePropertyChange, firePropertyChange, getBaseline, getBaselineResizeBehavior, getBounds, getBounds, getColorModel, getComponentListeners, getComponentOrientation, getCursor, getDropTarget, getFocusListeners, getFocusTraversalKeysEnabled, getFont, getFontMetrics, getForeground, getGraphicsConfiguration, getHeight, getHierarchyBoundsListeners, getHierarchyListeners, getIgnoreRepaint, getInputMethodListeners, getInputMethodRequests, getKeyListeners, getLocation, getLocation, getLocationOnScreen, getMouseListeners, getMouseMotionListeners, getMousePosition, getMouseWheelListeners, getName, getParent, getPropertyChangeListeners, getPropertyChangeListeners, getSize, getSize, getTreeLock, getWidth, getX, getY, gotFocus, handleEvent, hasFocus, imageUpdate, inside, isBackgroundSet, isCursorSet, isDisplayable, isDoubleBuffered, isEnabled, isFocusable, isFocusOwner, isFocusTraversable, isFontSet, isForegroundSet, isLightweight, isMaximumSizeSet, isMinimumSizeSet, isPreferredSizeSet, isValid, isVisible, keyDown, keyUp, list, list, list, location, lostFocus, mouseDown, mouseDrag, mouseEnter, mouseExit, mouseMove, mouseUp, move, nextFocus, paintAll, prepareImage, prepareImage, printAll, processComponentEvent, processFocusEvent, processHierarchyBoundsEvent, processHierarchyEvent, processInputMethodEvent, processKeyEvent, processMouseEvent, processMouseMotionEvent, processMouseWheelEvent, removeComponentListener, removeFocusListener, removeHierarchyBoundsListener, removeHierarchyListener, removeInputMethodListener, removeKeyListener, removeMouseListener, removeMouseMotionListener, removeMouseWheelListener, removePropertyChangeListener, removePropertyChangeListener, repaint, repaint, repaint, requestFocus, requestFocus, requestFocus, requestFocus, requestFocusInWindow, requestFocusInWindow, requestFocusInWindow, resize, resize, revalidate, setComponentOrientation, setDropTarget, setEnabled, setFocusable, setFocusTraversalKeysEnabled, setForeground, setIgnoreRepaint, setLocale, setMaximumSize, setMixingCutoutShape, setName, setPreferredSize, show, size, toString, transferFocus, transferFocusBackward, transferFocusUpCycle

Methods inherited from class java.lang.Object

clone, equals, finalize, getClass, hashCode, notify, notifyAll, wait, wait, wait

Methods inherited from interface java.awt.MenuContainer

getFont, postEvent

Field Details

_grayColor

static Color _grayColor

_darkGrayColor

static Color _darkGrayColor

colorChoice

static final Color[] colorChoice

Constructor Details

DisplayFrame

public DisplayFrame(boolean saveSize,
 boolean savePosition)

Create a JmriJFrame with standard settings, optional save/restore of size and position.

Parameters:

saveSize - set true to save the last known size

savePosition - set true to save the last known location

DisplayFrame

public DisplayFrame(String name,
 boolean saveSize,
 boolean savePosition)

Create a JmriJFrame with with given name plus standard settings, including optional save/restore of size and position.

Parameters:

name - title of the Frame

saveSize - set true to save the last knowm size

savePosition - set true to save the last known location

DisplayFrame

public DisplayFrame(String name,
 Editor editor)

Create a JmriJFrame for ItemPalette or for edit popups of a given editor panel. Such child classes need to provide backgrounds for their panes and panels.

Parameters:

name - title of the Frame

editor - editor of panel items

DisplayFrame

public DisplayFrame()

Create a JmriJFrame with standard settings, including saving/restoring of size and position.

DisplayFrame

public DisplayFrame(String name)

Create a JmriJFrame with with given name plus standard settings, including saving/restoring of size and position.

Parameters:

name - title of the JFrame

Method Details

setPreviewBg

public void setPreviewBg(int index)

This may be used as a callback to notify children of this class when the preview color has changed. Children of this class should override if there are several other members with separate preview panels. e.g. ItemPalette But prevent a loop when calling super in that process (bug in 4.21.3; fixed in 4.21.4)

Parameters:

index - index of selection in _backgrounds array

getPreviewBg

public int getPreviewBg()

getPreviewBackground

public BufferedImage getPreviewBackground()

getCurrentColor

public Color getCurrentColor()

Returns:

the color of the background of editor display panel

getBackground

public BufferedImage getBackground(int index)

updateBackground

public void updateBackground(Editor ed)

Called when the background of the display panel is changed.

Parameters:

ed - the editor of the display panel

getEditor

public Editor getEditor()

reSize

public void reSize(Container container,
 Dimension deltaDim,
 Dimension newDim)

Resizes this frame to accommodate the size of the tab panel when tab is changed. Otherwise it may force the tab panel to use scrollbars or be far oversized. As a trade off to keep right mouse arrow in same place for ItemPalette accept frame is wider in few cases.

Parameters:

container - Container to be resized

deltaDim - Size difference of container with old contents

newDim - Size of the new contents
